MECALUX

1x Mecalux Heavy Duty Longspan Shelving - 3000mm High - Blue & Orange

No reviews

Key Features:

  • Up to 850kg per level (UDL) - width and depths vary
  • Ideal for storing bulky, heavy duty loads
  • Wide variety of sizes available to suit your requirements
Height:
Shelf Type:
Chipboard
Number of Bays:
Colour:
Width (mm): 1200
Depth (mm): 600
Levels: 3
Load Per Shelf (UDL):
590kg
FROM ONLY WAS £324.99 EX.VAT
PRICE PROMISE
VIEW OPTIONS

Code: APJH

Code Description Dimensions (mm) Levels Load Per Shelf (UDL) Price Quantity
APJG 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1000 x 600 3 610kg £304.99

Not enough in stock. Only 0 instock!

APLR 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1000 x 900 3 300kg £359.99

Not enough in stock. Only 0 instock!

APJH 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1200 x 600 3 590kg £324.99

Not enough in stock. Only 10 instock!

APLS 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1200 x 900 3 300kg £363.99

Not enough in stock. Only 10 instock!

APJI 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1400 x 600 3 500kg £369.99

Not enough in stock. Only 22 instock!

APLT 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1400 x 900 3 320kg £379.99

Not enough in stock. Only 14 instock!

APJJ 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1825 x 600 3 850kg £392.99

Not enough in stock. Only 22 instock!

APLU 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1825 x 900 3 440kg £419.99

Not enough in stock. Only 14 instock!

APJK 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1900 x 600 3 810kg £398.99

Not enough in stock. Only 16 instock!

APLV 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 1900 x 900 3 440kg £425.99

Not enough in stock. Only 14 instock!

APJL 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 2300 x 600 3 670kg £449.99

Not enough in stock. Only 12 instock!

APLW 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 2300 x 900 3 500kg £484.99

Not enough in stock. Only 12 instock!

APJM 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 2700 x 600 3 550kg £484.99

Not enough in stock. Only 16 instock!

APLX 1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange 3000 x 2700 x 900 3 550kg £549.99

Not enough in stock. Only 14 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1000 x 600

Levels: 3

Load Per Shelf (UDL): 610kg

Code: APJG

£304.99

Not enough in stock. Only 0 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1000 x 900

Levels: 3

Load Per Shelf (UDL): 300kg

Code: APLR

£359.99

Not enough in stock. Only 0 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1200 x 600

Levels: 3

Load Per Shelf (UDL): 590kg

Code: APJH

£324.99

Not enough in stock. Only 10 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1200 x 900

Levels: 3

Load Per Shelf (UDL): 300kg

Code: APLS

£363.99

Not enough in stock. Only 10 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1400 x 600

Levels: 3

Load Per Shelf (UDL): 500kg

Code: APJI

£369.99

Not enough in stock. Only 22 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1400 x 900

Levels: 3

Load Per Shelf (UDL): 320kg

Code: APLT

£379.99

Not enough in stock. Only 14 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1825 x 600

Levels: 3

Load Per Shelf (UDL): 850kg

Code: APJJ

£392.99

Not enough in stock. Only 22 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1825 x 900

Levels: 3

Load Per Shelf (UDL): 440kg

Code: APLU

£419.99

Not enough in stock. Only 14 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1900 x 600

Levels: 3

Load Per Shelf (UDL): 810kg

Code: APJK

£398.99

Not enough in stock. Only 16 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 1900 x 900

Levels: 3

Load Per Shelf (UDL): 440kg

Code: APLV

£425.99

Not enough in stock. Only 14 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 2300 x 600

Levels: 3

Load Per Shelf (UDL): 670kg

Code: APJL

£449.99

Not enough in stock. Only 12 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 2300 x 900

Levels: 3

Load Per Shelf (UDL): 500kg

Code: APLW

£484.99

Not enough in stock. Only 12 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 2700 x 600

Levels: 3

Load Per Shelf (UDL): 550kg

Code: APJM

£484.99

Not enough in stock. Only 16 instock!

1x Mecalux Heavy Duty Longspan Shelving - Blue & Orange

3000 x 2700 x 900

Levels: 3

Load Per Shelf (UDL): 550kg

Code: APLX

£549.99

Not enough in stock. Only 14 instock!

Key Features of Mecalux Longspan Shelving


  • 1x Mecalux Longspan shelving bay 3000mm high
  • Industrial grade steel, Ideal for storing heavy duty, bulky loads
  • Tested to FEM standards
  • 2x frame uprights delivered fully assembled
  • Blue uprights powder coated finish
  • Levels are adjustable in height every 50mm
  • 2x safety locking pins per beam for extra security and to prevent dislodging
  • Powder coated orange finish on the beams
  • 3x chipboard decks, 22mm thickness
  • Up to 850kg load capacities per level for heavy duty storage (varies between the width and depth of the bay)
  • Ground level can be used for pallet storage - no bottom beams required
  • Floor fixings and steel leveling plates are provided
  • Boltless assembly (except when fixing to the floor)
  • Longspan shelving support beams are available for extra reinforcement to levels
  • Extension bays are available - expand your longspan shelving to maximise storage space



UDL (Uniformly Distributed Load) - The load capacities stated are the maximum weights each level can hold. This weight needs to be evenly distributed across each level.



Mecalux Longspan Shelving is one of our most robust shelving units. Perfect for use in an industrial/warehouse environment, these units can be used for a wide range of storage due to their large load capacity. It is constructed using high quality, thick upright frames and beams, once assembled these shelving units are impressively sturdy and reliable. Multiple sizes are available for your storage requirements, choose from up to 2700mm wide units, great for bulkier storage.



Ideal Uses:



  • Industrial Environment
  • Warehouses
  • Heavy Duty Storage





Code Frame Height (mm) Depth (mm) Beam Width (mm) External Bay Width (mm) Clear Entry per Bay (mm)
APJG 3000
600 1000 1100 990
APJH 3000 600 1200 1300 1190
APJI 3000 600 1400 1500 1390
APJJ 3000 600 1825 1925 1815
APJK 3000 600 1900 2000 1890
APJL 3000 600 2300 2400 2290
APJM 3000 600 2700 2800 2690
APLR 3000 900 1000 1100 990
APLS 3000 900 1200 1300 1190
APLT 3000 900 1400 1500 1390
APLU 3000 900 1825 1925 1815
APLV 3000 900 1900 2000 1890
APLW 3000 900 2300 2400 2290
APLX 3000 900 2700 2800 2690





Code Levels Shelf Thickness (mm) Chipboard Thickness (mm) Max. Load per Level Total Bay Capacity
APJG 3 57 22 610kg 4000kg
APJH 3 57 22 590kg 4000kg
APJI 3 57 22 500kg 4000kg
APJJ 3 77 22 850kg 4000kg
APJK 3 77 22 810kg 4000kg
APJL 3 77 22 670kg 4000kg
APJM 3 87 22 550kg 4000kg
APLR 3 57 22 300kg 4000kg
APLS 3 57 22 300kg 4000kg
APLT 3 57 22 320kg 4000kg
APLU 3 77 22 440kg 4000kg
APLV 3 77 22 440kg 4000kg
APLW 3 77 22 500kg 4000kg
APLX 3 87 22 550kg 4000kg



SX400 Industrial Shelving Guide

PRODUCT CATEGORY PRODUCT DESCRIPTION DOWNLOAD LINK
Longspan Shelving Assembly Instructions - Longspan Shelving DOWNLOAD
Longspan Shelving Guide - Longspan Shelving DOWNLOAD
